MIG-C  Inverter

MIG-C Inverter

DESCRIPTION:

● Inverter technology IGBT switches, energy saving, can load wire max 300 mm(15kg).

● Single phase or Three phase; power input, DC output, suitable for gas or gasless welding process.

● Multifunctiton for MMA welding and MIG/MAG welding process, strong wire feeder built-in.

● Stepless regulation for welding voltage and wire speed, automatic protection for over heat and over current.

OPTIONAL:

● MMA Function

0
Views: 73

Details

Model

MIG-200C

MIG-230C

MIG-250C

MIG-250/2C

Rated Input Voltage (V)

230

230

230

230/400

No-load Voltage (V)

56

56

56

54

Current Range (A)

40-200

40-230

40-250

40-250

Fuse (A)

20

23

25

25/16

Duty Cycle (%)

60%

60%

60%

60%

Max Spool Diameter(mm)

300

300

300

300

Max Wire Diameter (mm)

1.0

1.0

1.0

1.0

Weight (Kg)

19

19.5

19.5

20
