CD BATTERY CHARGER TRANSFORMER

CD BATTERY CHARGER TRANSFORMER

DESCRIPTION:

● Single-phase Portable Battery Chargers For Charging Lead-acid Batteries With 12/24 voltage.

● Protected Against Overloads And Polarity Reversal

● Equipped With Selector For Normal Or Quick (Boost) charge

● Equipped With Ampmeter.

INCLUDED ACCESSORIES:

● Battery Clamp

● Cable



0
Views: 59

Details

Model

CD-100

CD-150

CD-200

CD-300

CD-400

CD-500

CD-600

CD-800

CD-1000

Rated Input Voltage (V)

230

230

230

230

230

230

230

230

400

Rated Capacity (w)

0.3/1.5

0.4/2

0.8/3.6

1.0/6.4

1.4/8

1.6/10

2.0/12

2.5/16

2.6/18

Charging voltage (V)

12/24

12/24

12/24

12/24

12/24

12/24

12/24

12/24

12/24

Effiective Charging Current (A)

15

22

30

45

60

75

90

100

120

Rated charge Current (A)

10

15

20

30

40

50

60

70

80

Starting Current (A)

80

100

120

180

240

300

360

600

800

Min/max. Reference Capacity (Ah)

20-200

20-300

20-400

20-500

40-700

40-800

40-1000

40-1200

40-1300

Insulation Class

H

H

H

H

H

H

H

H

H

Weight (Kg)

6

8

13

17

19

27

28

32

35
